DipTrace is quality Schematic Capture and PCB Design software that offers everything to create simple or complex multi-layer boards from schematic to manufacturing files.
Intelitech is an authorized DipTrace distributor in Latvia, Germany, Sweden and Finland
DipTrace is first of its kind intuitive CAD software, featuring:
- Easy to learn User Interface
- Multi-sheet and hierarchical schematics
- Shape-based autorouter
- Smart manual routing tools
- Wide import/export capabilities
- High-speed signaling
- Advanced verifications and Real-time DRC
- Real-time 3D PCB preview & STEP export
- Manufacturing output
- Commitment to the future
After a couple of hours you become productive with simple boards and then improve your skills step-by-step. Basic features are enough for simple projects and advanced capabilities should be used for complex circuit boards.
All DipTrace modules share similar interface conceptions and design basics. The tutorial contains detailed instructions for all stages of the board design. It is included in the DipTrace installation package.
A 30-day full-featured trial, various DipTrace Editions and upgrade without overcharge will satisfy even the most cost-concious managers.
